Solving MCAT Sound Problems: From Decibel Logs to Doppler Shifts

When a student sees a problem involving a sound wave moving from air into the human body, the most frequent error is assuming the frequency changes. In reality, the frequency is determined strictly by the source, while the speed and wavelength adjust based on the medium's bulk modulus. If you fail to recognize that sound travels faster in the denser, less compressible environment of soft tissue than in air, your calculation for wavelength will be fundamentally flawed before you even plug a single number into the v = fλ equation.

Another common hurdle is the logarithmic nature of the decibel scale. Increasing sound intensity by a factor of 100 does not mean the sound is 100 times louder in decibels; it represents a specific 20 dB shift. This requires a quick mental conversion of intensity ratios into powers of ten. This guide focuses on these specific mechanical transitions and the sign conventions of the Doppler effect, ensuring you can distinguish between the perceived frequency and the source frequency when both the detector and source are in motion.

Wave Mechanics and Acoustic Properties

MCAT Waves and Sound refers to the study of periodic disturbances that transport energy through a medium (mechanical waves) or vacuum (electromagnetic waves), characterized by properties such as frequency, wavelength, amplitude, and speed. Mechanical waves, like sound, require a physical medium to propagate. Sound is a longitudinal wave, meaning the particles of the medium oscillate parallel to the direction of energy transfer, creating regions of compression and rarefaction. In contrast, transverse waves involves oscillations perpendicular to the direction of propagation.

Key variables and formulas you must memorize for the MCAT include:

• Wave Speed: $v = f \lambda$, where $v$ is velocity, $f$ is frequency, and $\lambda$ is wavelength.
• Period: $T = \frac{1}{f}$, representing the time taken for one complete cycle.
• Sound Intensity: $I = \frac{P}{A}$, where $P$ is power and $A$ is area. Intensity is measured in decibels (dB) using the logarithmic scale: $\beta = 10 \log \frac{I}{I_0}$.
• Doppler Effect: Describes the change in perceived frequency due to relative motion between a source and a detector: f' = f \left( \frac{v \pm v_d}{v \mp v_s} ight)

The speed of sound depends on the properties of the medium. It travels fastest in solids and slowest in gases because solids have a higher bulk modulus (stiffness). You can explore more about energy transformations in our Easy MCAT Redox Practice Questions guide, which touches on electronic shifts that, while different, rely on similar fundamental physical principles. For a deeper look at wave behavior, resources like OpenStax University Physics provide excellent visualizations of longitudinal pressure waves.

Solved Examples

Example 1: Calculating Wavelength
A diagnostic ultrasound probe emits a frequency of 5 MHz. If the speed of sound in human soft tissue is approximately 1540 m/s, what is the wavelength of the wave?

1. Identify the given values: $f = 5 \times 10^6 \text{ Hz}$, $v = 1540 \text{ m/s}$.
2. Use the wave speed formula: $v = f \lambda$.
3. Rearrange for wavelength: $\lambda = \frac{v}{f}$.
4. Substitute the values: $\lambda = \frac{1540}{5 \times 10^6}$.
5. Calculate: $\lambda = 3.08 \times 10^{-4} \text{ m}$ or 0.308 mm.

Example 2: Intensity Level Change
The intensity of a sound is increased by a factor of 100. By how many decibels does the sound level increase?

1. Recall the decibel formula: $\Delta \beta = 10 \log \frac{I_f}{I_i}$.
2. Substitute the ratio: $\frac{I_f}{I_i} = 100$.
3. Calculate the log: $\log(100) = \log(10^2) = 2$.
4. Multiply by 10: $\Delta \beta = 10 \times 2 = 20 \text{ dB}$.

Example 3: Standing Waves in a Pipe
An organ pipe is closed at one end and has a length of 0.85 m. What is the fundamental frequency if the speed of sound is 340 m/s?

1. Identify the pipe type: Closed at one end (one node, one antinode).
2. Recall the formula for wavelength of the nth harmonic in a closed pipe: $\lambda = \frac{4L}{n}$ (where $n = 1, 3, 5...$).
3. For the fundamental frequency, $n = 1$. So, $\lambda = 4 \times 0.85 = 3.4 \text{ m}$.
4. Calculate frequency: $f = \frac{v}{\lambda} = \frac{340}{3.4} = 100 \text{ Hz}$.

Practice Questions

1. A sound wave travels from air into water. Which of the following properties of the wave remains constant during this transition?

2. A person stands 10 meters away from a speaker, and the sound intensity level is 60 dB. If the person moves to a distance of 100 meters, what is the new intensity level in dB?

3. Two waves with the same frequency and amplitude of 5 cm interfere. If they are exactly $180^\circ$ out of phase, what is the amplitude of the resulting wave?

4. An ambulance siren has a frequency of 800 Hz. If the ambulance is moving toward a stationary observer at 34 m/s, what frequency does the observer hear? (Assume speed of sound = 340 m/s).

5. A string fixed at both ends is 2 meters long. If the speed of a wave on the string is 100 m/s, what is the frequency of the third harmonic?

6. If the bulk modulus of a material increases while its density remains the same, how does the speed of sound through that material change?

7. A pipe open at both ends has a fundamental frequency of 250 Hz. If one end is then closed, what will the new fundamental frequency be?

8. Which of the following best describes the relationship between the period $T$ and the angular frequency $\omega$ of a wave?

9. A source of sound emits 0.1 Watts of power uniformly in all directions. What is the intensity at a distance of 2 meters?

10. During a medical procedure, a laser (EM wave) travels from a vacuum into a lens. If the index of refraction of the lens is 1.5, what is the speed of the wave in the lens? (Speed of light $c = 3 \times 10^8 \text{ m/s}$).

Answers & Explanations

1. Frequency: When a wave changes media, its speed and wavelength change, but its frequency is determined by the source and remains constant.
2. 40 dB: Sound intensity follows the inverse square law ($I \propto 1/r^2$). Increasing distance from 10m to 100m is a 10-fold increase in distance, which is a 100-fold decrease in intensity ($10^2 = 100$). A 100-fold decrease corresponds to a drop of 20 dB ($10 \log 100 = 20$). $60 - 20 = 40 \text{ dB}$.
3. 0 cm: Waves that are $180^\circ$ out of phase undergo complete destructive interference. Since the amplitudes are equal, they cancel each other out entirely.
4. 889 Hz: Using the Doppler formula $f' = f \frac{v}{v - v_s}$. $f' = 800 \frac{340}{340 - 34} = 800 \frac{340}{306} \approx 888.8 \text{ Hz}$.
5. 75 Hz: For a string fixed at both ends, $\lambda = \frac{2L}{n}$. For $n = 3$, $\lambda = \frac{2 \times 2}{3} = 1.33 \text{ m}$. $f = \frac{v}{\lambda} = \frac{100}{1.33} = 75 \text{ Hz}$.
6. It increases: The speed of sound is given by $v = \sqrt{\frac{B}{ ho}}$. If bulk modulus $B$ increases and density $ho$ is constant, $v$ must increase.
7. 125 Hz: An open pipe has $\lambda = 2L$. A closed-at-one-end pipe has $\lambda = 4L$. Since the wavelength doubles, the frequency must be halved ($250 / 2 = 125$).
8. $\omega = \frac{2\pi}{T}$: Angular frequency is defined as $2\pi f$. Since $f = 1/T$, the relationship is $\omega = \frac{2\pi}{T}$.
9. $0.002 \text{ W/m}^2$: $I = \frac{P}{4\pi r^2}$. $I = \frac{0.1}{4 \times \pi \times 2^2} = \frac{0.1}{16\pi} \approx 0.002 \text{ W/m}^2$.
10. $2 \times 10^8 \text{ m/s}$: The index of refraction $n = c/v$. Therefore, $v = c/n = (3 \times 10^8) / 1.5 = 2 \times 10^8 \text{ m/s}$.

Frequently Asked Questions

What is the difference between transverse and longitudinal waves?

Transverse waves oscillate perpendicular to the direction of travel (e.g., light), while longitudinal waves oscillate parallel to the direction of travel (e.g., sound).

How does the Doppler effect apply to medical imaging?

Doppler ultrasound measures the frequency shift of sound waves reflecting off moving red blood cells to determine the velocity and direction of blood flow. This principle is vital for diagnosing vascular conditions and heart valve function.

Does sound travel faster in hot or cold air?

Sound travels faster in hot air because the molecules have more kinetic energy and can transmit the vibration more quickly. The speed of sound in air is approximately $331 \text{ m/s} + 0.6T$, where $T$ is the temperature in Celsius.

What are harmonics in the context of the MCAT?

Harmonics are integer multiples of the fundamental frequency of a standing wave. On the MCAT, you must distinguish between strings/open pipes (all harmonics present) and closed pipes (only odd harmonics present).

What is the relationship between wave intensity and amplitude?

Intensity is proportional to the square of the amplitude ($I \propto A^2$). If the amplitude of a wave is doubled, its intensity increases by a factor of four.
