Hard Polarity Determination Practice Questions

Concept Explanation

Polarity determination is the process of evaluating whether a molecule possesses a net dipole moment by analyzing the electronegativity differences between atoms and the overall three-dimensional molecular geometry. To determine if a molecule is polar or nonpolar, you must first construct its Lewis structure to identify the arrangement of electrons. If a molecule has polar bonds (typically an electronegativity difference between 0.5 and 1.7) and these bonds are arranged asymmetrically, the molecule will be polar. Conversely, if the polar bonds are arranged symmetrically so that the individual bond dipoles cancel out, the molecule is nonpolar. This concept is deeply rooted in the VSEPR theory, which dictates the spatial orientation of electron domains. In advanced chemistry, polarity determination requires distinguishing between electronic geometry and molecular geometry, especially when lone pairs are present on the central atom, as these often disrupt symmetry and lead to a permanent dipole moment.

Solved Examples

1. Determine the polarity of Sulfur Tetrafluoride (SF4).

   1. Count valence electrons: S (6) + 4F (7 × 4) = 34 electrons.

   2. Draw the Lewis structure: S is the central atom with four S-F bonds and one lone pair.

   3. Determine the geometry: The molecule has 5 electron domains (AX4E), resulting in a see-saw molecular geometry based on a trigonal bipyramidal electron geometry.

   4. Analyze bond dipoles: S-F bonds are highly polar due to the high electronegativity of fluorine.

   5. Evaluate symmetry: In a see-saw shape, the equatorial bond dipoles and axial bond dipoles do not perfectly cancel out due to the presence of the lone pair.

   6. Conclusion: SF4 is polar.

2. Determine the polarity of Xenon Difluoride (XeF2).

   1. Count valence electrons: Xe (8) + 2F (14) = 22 electrons.

   2. Draw the Lewis structure: Xe is the central atom with two Xe-F bonds and three lone pairs.

   3. Determine the geometry: 5 electron domains (AX2E3) result in a linear molecular geometry.

   4. Analyze bond dipoles: The two Xe-F bonds are polar and point in exactly opposite directions (180 degrees).

   5. Evaluate symmetry: The three lone pairs occupy the equatorial positions of the trigonal bipyramid, and the two F atoms are at the poles. The dipoles cancel perfectly.

   6. Conclusion: XeF2 is nonpolar.

3. Determine the polarity of Bromine Pentafluoride (BrF5).

   1. Count valence electrons: Br (7) + 5F (35) = 42 electrons.

   2. Draw the Lewis structure: Br has five single bonds to F and one lone pair.

   3. Determine the geometry: 6 electron domains (AX5E) result in a square pyramidal molecular geometry.

   4. Analyze bond dipoles: Br-F bonds are polar.

   5. Evaluate symmetry: While the four equatorial F atoms cancel each other out, the axial F atom is opposite a lone pair. This creates an imbalance in charge distribution.

   6. Conclusion: BrF5 is polar.

Practice Questions

Challenge yourself with these hard polarity determination practice questions. Ensure you have a periodic table handy to check electronegativity values as needed.

1. Identify whether Phosphorus Pentachloride (PCl5) is polar or nonpolar and justify your answer using its molecular geometry.

2. Consider the molecule SO2. Predict its polarity and explain how its VSEPR geometry differs from CO2.

3. Analyze the molecule ClF3 (Chlorine Trifluoride). Determine its molecular shape and whether it possesses a net dipole moment.

4. Evaluate the polarity of the Polyatomic ion I3⁻. Even though it is an ion, does it have a symmetric charge distribution?

5. Compare CH3Cl and CCl4. Which one is polar, and why does the substitution of all hydrogen atoms with chlorine change the polarity?

6. Determine the polarity of SF6 (Sulfur Hexafluoride).

7. Analyze PF3Cl2. Assuming the Cl atoms occupy the axial positions, is this molecule polar or nonpolar?

8. Determine the polarity of Ozone (O3). Even though all atoms are the same element, is the molecule polar?

9. Identify the polarity of XeF4 (Xenon Tetrafluoride).

10. Consider the molecule TeCl4. Determine its molecular geometry and net dipole status.

4. Answers & Explanations

1. PCl5: Nonpolar. Phosphorus pentachloride has a trigonal bipyramidal geometry with no lone pairs on the central atom. The three equatorial Cl atoms cancel each other out at 120-degree angles, and the two axial Cl atoms cancel each other out at 180-degree angles.

2. SO2: Polar. Unlike CO2, which is linear and nonpolar, SO2 has a lone pair on the sulfur atom. This results in a bent molecular geometry. The S-O bond dipoles do not cancel, leading to a net dipole moment.

3. ClF3: Polar. Chlorine trifluoride has 5 electron domains (2 lone pairs, 3 bonds), resulting in a T-shaped molecular geometry. The asymmetric arrangement of the T-shape prevents the Cl-F bond dipoles from canceling.

4. I3⁻: Nonpolar (Symmetric). The triiodide ion has a linear molecular geometry (AX2E3). The three lone pairs are in the equatorial plane, and the two terminal Iodine atoms are 180 degrees apart, creating a symmetric distribution of charge.

5. CH3Cl is polar; CCl4 is nonpolar. In CH3Cl, the C-Cl bond is much more polar than the C-H bonds, creating an asymmetric charge distribution. In CCl4, the tetrahedral symmetry ensures that all four C-Cl bond dipoles cancel perfectly.

6. SF6: Nonpolar. Sulfur hexafluoride has an octahedral geometry. All six S-F bonds are identical and positioned 90 and 180 degrees from each other, leading to complete cancellation of dipoles.

7. PF3Cl2 (axial Cl): Nonpolar. If the two Cl atoms are axial, they cancel each other out. If the three F atoms are equatorial, their dipoles also cancel out at 120-degree angles. This high symmetry results in a nonpolar molecule.

8. O3: Polar. Ozone has a bent molecular geometry due to a lone pair on the central oxygen atom. Even though the O-O bonds have very little electronegativity difference, the formal charges and the geometry create an uneven electron distribution.

9. XeF4: Nonpolar. Xenon tetrafluoride has 6 electron domains (2 lone pairs, 4 bonds). The lone pairs occupy the axial positions, and the 4 F atoms form a square planar molecular geometry. The F-Xe-F bonds are 180 degrees apart, canceling all dipoles.

10. TeCl4: Polar. Tellurium tetrachloride has a see-saw geometry (similar to SF4). The presence of one lone pair on the Te atom disrupts the symmetry, meaning the Te-Cl bond dipoles do not cancel.

5. Quick Quiz

6. Frequently Asked Questions

Can a molecule with polar bonds be nonpolar?

Yes, a molecule can be nonpolar if it has a highly symmetric geometry that allows the individual bond dipoles to cancel each other out. Common examples include CO2, CCl4, and BF3.

How do lone pairs affect the polarity of a molecule?

Lone pairs usually decrease the symmetry of a molecule, often leading to a polar classification. They exert greater repulsive forces than bonding pairs, which distorts the bond angles and prevents bond dipoles from canceling.

What is the difference between electronic and molecular geometry?

Electronic geometry considers all electron domains (bonds and lone pairs) around a central atom, while molecular geometry describes only the spatial arrangement of the atoms. Polarity depends on the actual molecular geometry.

Is water (H2O) polar or nonpolar?

Water is a highly polar molecule because it has a bent molecular geometry due to two lone pairs on the oxygen atom. This prevents the polar O-H bonds from canceling their dipoles.

Does electronegativity alone determine polarity?

No, electronegativity only determines the polarity of individual bonds. The overall molecular polarity is determined by the vector sum of all bond dipoles, which depends on the molecular geometry.

How can I predict if a central atom has lone pairs?

You can predict lone pairs by calculating the number of valence electrons and drawing a Lewis structure. Subtract the electrons used in bonds from the total valence electrons to see what remains as lone pairs on the central atom.
